功用与介简/Brief Introduction：

这手机是抗衡服用液波璃瓶的新食品，齐全改善了近半年服用液波璃瓶的较差郊果。这类灌封机所需的材料瓶，非但不是需求洗瓶机、烘箱机，更不是需求杀菌，都可以进行灌封。这手机全自然理瓶、进瓶、包装，包装量固定性高，无漏滴，无瓶不包装。上盖、粘口率能够达到100%。此机技术工艺先进的，体积大小小、电脑运行固定性高、燥音低，操作的维修费、擦洗快捷等显著特点，齐全相符合GMP标准规定。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本型号查询有低速度和髙速三种时产供您会选择。Note: this model has two kinds of low speed and high-speed production for your choice.

的特点 Characteristic

◆机器符合于所有易折瓶口服方式液记量灌装生产线和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆大多数电嚣部件均通过有名品店牌。All electrical components adopt famous brand◆该机运行抽象化以便于，无瓶不灌装设备，量值溯源*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料管瓶灌封机的主要型式与操作过程Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折PVC瓶灌封机大部分理瓶器、理盖器、主传动链系统化、搜集带孔径送桶裝置、瓶子检漏裝置、包装安装、清除裝置、热溶封安装、手动机诫手腕夹瓶安装、伺服线束发电机孔径上瓶安装与出瓶安装等組成。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机运用的胶囊液易折塑瓶、盖就是定洁净间区生产加工的，需要药袋材许证证，故而瓶身与底盖经转递和"去项目外包"后可可以进人灌封间。能够理盖器、理瓶器的半自动方向收纳，去掉反向的方式给回底盖及瓶身底口朝下的瓶，使方向后的包材喂料有要求地进人传送导轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向分配后服食液易折可塑胶瓶在输料轨道列车第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

的技术性能指标technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封膜率Hot sealing intensity	》99%
装量随机误差The load error	《1.5%
损坏率damage rate	《1.0%
工作电压power	2KW	3KW
主机电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
毛重 Weight	700Kg	800Kg
